The Audison Prima Series 6×9″ APK 690 is designed for drivers who demand superior sound performance in vehicles with limited space. These 2-way component systems combine high-efficiency woofers with Audison’s renowned Tetolon dome tweeters to deliver clear, detailed audio and impressive dynamics—even with factory head units or low-power amplifiers.
Each APK kit features water-repellent treated paper cones for lightweight strength and responsive bass, while the soft Tetolon tweeters reproduce delicate highs with remarkable clarity and minimal distortion. Compact crossovers ensure easy installation, even in tight factory locations, making the APK series a perfect choice for OEM speaker upgrades.
-
Smooth, Balanced Sound: Accurate highs, natural mids, and controlled bass for a well-rounded listening experience.
-
Premium Materials: Treated paper woofers and Tetolon soft dome tweeters provide clarity and long-lasting durability.
-
OEM-Friendly Fit: Shallow mounting depth and compact crossover design simplify installation in factory locations.
-
Flexible System Building: Designed for seamless integration with Prima amplifiers and DSP systems for future system expansion.
Whether you’re replacing tired factory speakers or taking the first step toward a full custom system, the Audison Prima APK series brings high-fidelity sound to any vehicle.
Features
AP 1 Tweeter
- 26 mm diameter diaphragm combined with a wide-roll surround provides maximum efficiency and reduced resonance frequency.
- Acoustic lens designed to compensate for the in-car frequency response in the 10kHz 13kHz bandwidth caused by critical OEM placements.
AP 690 Woofer
- 25 mm pure copper voice coil, for high power handling and outstanding low frequency control.
- Water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel R&D Scan Vibrometer.
- Reduced mounting depth, providing ease of installation in OEM placements.
- “Triple wave” surround profile for maximum linearity of excursion.
- Compact basket, protected by abrasion-resistant and scratchproof coating, the motor affixed with damping epoxy adhesive.
- High current fast-on terminal with double contact on positive and negative poles for high flexibility and quick connection.
APCX TW 690 Crossover
- Optimized for OEM Integration featuring an attenuation switch(0 dB, +3dB) to tune the in-car response according to different installation conditions.
- Supplied with fast-on connectors that eliminate any possible connection errors.
Size | |
---|---|
Driver Design | |
Power Handling Peak | |
Power Handling RMS | |
Cone Material | |
Frequency Response |
